MTH: VO1000 - Photo and Video page:

(Click here for MTH: VO1000 - Repair/Modification Page)

Model Info:

• MTH Product Pages:
  • Baltimore and Ohio - #9220, 9224: (70-2070-1 - w/PS2):  http://www.mthtrains.com/70-2070-1
  • Budweiser - #1876, 2010: (70-2063-1 - w/PS2):  http://www.mthtrains.com/70-2063-1
  • Chicago Burlington & Quincy - #9372: (70-2092-1 - w/PS3):  http://www.mthtrains.com/70-2092-1  - ** Never produced production cancelled **
  • Coors - #100, 101: (70-2064-1 - w/PS2):  http://www.mthtrains.com/70-2064-1
  • Great Northern - #137, 140: (70-2065-1 - w/PS2):  http://www.mthtrains.com/70-2065-1
  • Harley Davidson - #2010, 2011: (70-2066-1 - w/PS2):  http://www.mthtrains.com/70-2066-1
  • New York Central - #9306, 9305: (70-2045-1 - w/PS2):  http://www.mthtrains.com/70-2045-1
  • Northern Pacific - #416, 421: (70-2067-1 - w/PS2):  http://www.mthtrains.com/70-2067-1
  • Pennsylvania - #5913, 5914: (70-2047-1 - w/PS2):  http://www.mthtrains.com/70-2047-1
  • Pennsylvania - #5916: (70-2093-1 - w/PS3):  http://www.mthtrains.com/70-2093-1  - ** Never produced production cancelled **
  • Reading - #86: (70-2049-1 - w/PS2):  http://www.mthtrains.com/70-2049-1
  • Santa Fe - #2244: (70-2046-1 - w/PS2):  http://www.mthtrains.com/70-2046-1
  • Santa Fe - #2226: (70-2094-1 - w/PS3):  http://www.mthtrains.com/70-2094-1  - ** Never produced production cancelled **
  • Seaboard - #1402: (70-2050-1 - w/PS2):  http://www.mthtrains.com/70-2050-1
  • Southern - #2205: (70-2068-1 - w/PS2):  http://www.mthtrains.com/70-2068-1
  • Southern Pacific - #1380, 1384: (70-2069-1 - w/PS2):  http://www.mthtrains.com/70-2069-1
  • Southern Pacific - #1858: (70-2095-1 - w/PS3):  http://www.mthtrains.com/70-2095-1  - ** Never produced production cancelled **
  • Union Pacific - #1200: (70-2048-1 - w/PS2):  http://www.mthtrains.com/70-2048-1
  • Western Maryland - #129, 313: (70-2051-1 - w/PS2):  http://www.mthtrains.com/70-2051-1
• Owners Manual: VO1000-OwnersManual.pdf (For all VO1000s)
• PS2 Sound File:
  • All VO1000s (Except Special): g101pf3_vo1000_all091215af2x.mth
    • Budweiser - #1876, 2010: (70-2063-1 - w/PS2): g101pf3_vo1000_ber091215bf2x.mth
    • Harley Davidson - #2010, 2011: (70-2066-1 - w/PS2): g101pf3_vo1000_hd_091214bfin.mth
    • Coors - #100, 101: (70-2064-1 - w/PS2): g101pf3_vo1000_ber091215bf2x.mth
• Parts Diagram:  **Not available**
• Unit measurements:  18 5/16" x 5 7/16" x 3 11/16"
• Repairs/Modifications: VO1000 - Repair/Mods

MTH One Gauge Catalogs:

• 2001(see page 90) - 2003 - 2004 - 2005 - 2006 - 2007 - 2010 - 2011 - 2013 - 2015 - 2017 - 2018(BigBoy) - 2019/2020

Model Overview:

The VO1000 is the first switcher diesel MTH released.

• Detail is excellent and true to prototype with key detail parts being made of metal/brass
• Engine has all Die-cast metal frame
• Wheels, Axles and all gears (worm and axle) are all metal for long life
  • Eliminates failures seen in other mfg engines: Gear & Motor bearing failures
• Equipped with traction tires for greatly increased pulling power for minimal engine weight
• Equipped with remote triggered Proto-couplers

Note:  To fill the smoke unit, lift the door/hatch on the center top of the engine and add through the hole in the middle.  Don't add through any of the four smoke stacks.

________________________________________________________________________________

MTH VO1000 - Photos & Videos:

09/12/2014

Stock photos of road names published in the MTH catalogs:

(Note:  Red Pennsylvania engine was not produced.)
